Working-hours: only 14500 (06-23)
– Format – max. 750 x 1050 mm
– min. 350 x 400 mm
– Net cutting area 727 x 1050 mm
– Materials:
– paper min. 80 g/m²
– solid board up to 1400 g/m²
– corrugated board
B-flute up to 4 mm
– Cutting Pressure max. 300 tons
– Speed max. 7500 Sh/h
– Pile height at feeder 1000 mm (Non-Stop)
– Fully automatic diecutting-, grooving- and embossing machine
– Touch screen control
– stripping-station for internal waste, side- and rear sheet edges
– Centerline-system
– Small-size device min. 300×350 mm
– Non-Stop automatic feeder with preloading system
– Non-Stop standard delivery
– Register system in feeder and punch station
– mechanical double sheet control
– side-lays on operating- and drive side, switchable as pull- or push-lay
– 4 active front-lays with sensors for stop-control
– splitted fine adjustment of front-lays for drive- and operating side
– Gripper-edge adjustable 10-18 mm
– Delivery with gripper-edge removal
– Stripe insertion device in delivery
– Central and automatic chain lubrication
– 2 standard stripping frames
– 2 diecutting chases
– Diecutting plate 5 mm
– Screw-compressor Varimatrix 105-CS
